NOYITO AC to DC Precision Buck Power Supply Module AC 120V 100V-264V to 3.3V 700mA Isolated Step-Down DC Module (3.3V 700mA)

Description Isolated Precision Buck Power Supply Module ，Wide voltage range input with overload, short circuit, over temperature protection. Ultra-small size and high efficiency. Output parameters: Output voltage: 3.3V ±1%. Output current: 700mA. Ripple: less than 60mVp-p. Output accuracy: ±1%. Voltage regulation rate: ±1%. Load adjustment rate: ±1.2% Rated power: 2.4W. Output adjustable range: not adjustable. Establish, rise, hold time: 500ms, 80ms, 80ms / 220V AC. Input parameters: Input voltage range: AC 100- 264V. Input current: less than 0.2A. (Average current 0.03A-0.1A). Frequency range: 47-63Hz. Efficiency: about 80%. Start surge current: COLD START 30A/230V / AC. Leakage current: less than 2mA / 220V AC. Protection features: Over power protection: 150-170% rated power. (Fault removal is automatically restored). Overvoltage protection: VH: >50%. DC short circuit protection: The power supply is intermittently separated. (Recovery is automatically restored). Environmental parameters: Working temperature: -15 ° C - +50 ° C @ 100% LOAD , +60 ° C @ 60% LOAD; Working humidity: 20%-90% RH. Storage temperature, humidity: -20 ° C - +85 ° C, 10% -95% RH. Safety and EMC standards: Withstand voltage: I/P-O/P: 1KV AC 1min. Insulation resistance: I/P-O/P: 500VDC / 100M Ohms. Package Included: 1Pcs 3.3V 700mA AC-DC Precision Buck Power Supply Module

• Isolated Precision Buck Power Supply Module ，Wide voltage range input with overload, short circuit, over temperature protection. Ultra-small size and high efficiency.
• Input voltage range: AC 120V 100- 264V. Frequency range: 47-63Hz.
• Output voltage: 3.3V ±1%. Output current: 700mA.
• Ripple: less than 60mVp-p. Output accuracy: ±1%. Voltage regulation rate: ±1%
